CyberPower OLS2000E 2000VA/1800W Online UPS LCD
€598.31 ex. VAT | €711.99 inc. VAT
Availability: In Stock
Product Description
CyberPower OLS2000E is a high-performance UPS featuring online double-conversion topology, which provides seamless pure sine wave power for mission-critical devices such as NAS and servers, DVRs/surveillance systems, transportation and infrastructure, and emergency systems. It’s typically integrated in the back office, server room, and data center environment.
By manually setting the UPS to ECO Mode, the UPS automatically detects the input power quality and discerns whether it should operate in Line Mode or ECO Mode. Under poor power conditions, the UPS will run in Line Mode, which guarantees the highest level of protection and the best possible power quality. When the input power quality is acceptable, the UPS switches to ECO Mode, which increases the total output power efficiency by up to 96%.
The product is equipped with a Maintenance Bypass Switch. By flipping the switch, the power supply is safely transferred to utility. This allows service personnel to carry out fast on-site maintenance without having to shut down any connected equipment.
FEATURES
- Online (Double Conversion) UPS Topology
- Energy Saving Technology
- Generator Compatible
- Overload Protection
- Zero Transfer Time
- Smart Battery Management (SBM)
- Extended Battery Module (EBM)
- Surge and Spike Protection
- EMI and RFI Filtration
- Phone/Fax/Modem/DSL/Network Protection
- LCD Status Display
- Emergency Power Off (EPO) Port
- PowerPanel® Management Software
- SNMP/HTTP Remote Management Capability (Optional)
- Tower Form Factor
TYPICAL APPLICATION
- Data Closets
- NAS & Servers
- Home Theater Systems
- DVRs/Surveillance Systems
- POS Systems
- Transportation & Infrastructure
- Vehicle/Yacht
- Emergency Systems
- Electric Lighting
- Back Office
- Server Room
- Data Center
To download the latest Power Panel software please visit the website below:
https://www.cyberpower.com/uk/en/product/sku/OLS2000E
GENERAL
UPS Topology: Online Double Conversion
Energy Saving Technology: Online ECO Mode Efficiency > 95%
Active PFC Compatibility: Yes
Active PFC Compatibility: Yes
INPUT
Generator Compatibility: Yes
Nominal Input Voltage (Vac): 230 ± 10%
Adjustable Voltage Range (Vac): 0~50% Load for 110 ~ 300 Vac,
0~60% Load for 120 ~ 300 Vac,
0~80% Load for 140 ~ 300 Vac,
0~100% Load for 160 ~ 300 Vac
Input Frequency (Hz): 50 ± 10, 60 ± 10
Input Frequency Detection: Auto-sensing
Rated Input Current (A): 9
Input Power Factor: 0.98
Input Connector Type: IEC C20
Detachable Power Cord Plug Type: Schuko
OUTPUT
Capacity (VA): 2000
Capacity (Watts): 1800
On Battery Waveform: Pure Sine Wave
On Battery Voltage(s) (Vac): 208 ± 1%, 220 ± 1%, 230 ± 1%, 240 ± 1%
Output Voltage Setting: Configurable
On Battery Frequency (Hz): 50 ± 0.5%, 60 ± 0.5%
Output Frequency Setting: Configurable
ECO Mode Voltage Tolerance: ± 15 %
Overload Protection: Internal Current Limiting , Circuit Breaker , Fuse
Overload Protection (Line Mode): 110~120% Load for 1 min, >120% Load Immediately
Overload Protection (Battery Mode): 110~120% Load for 10 sec, >120% Load Immediately
Overload Protection (Bypass Mode): >130% Load Immediately
Crest Factor: 3 : 1
Harmonic Distortion (Linear Load): THD<3%
Harmonic Distortion (Non-linear Load): THD<5%
Internal Bypass: Automatic Bypass , Manual Bypass
Overload Protection: Internal Current Limiting , Circuit Breaker , Fuse
Overload Protection (Line Mode): 110~120% Load for 1 min, >120% Load Immediately
Overload Protection (Battery Mode): 110~120% Load for 10 sec, >120% Load Immediately
Overload Protection (Bypass Mode): >130% Load Immediately
Crest Factor: 3 : 1
Harmonic Distortion (Linear Load): THD<3%
Harmonic Distortion (Non-linear Load): THD<5%
Internal Bypass: Automatic Bypass , Manual Bypass
Outlet(s) – Total: 5
Outlet Type: Hardwire Terminal block x 1, IEC C13 x 4
Outlet(s) – Battery & Surge Protected: 4
Typical Transfer Time (ms): 0
BATTERY
Runtime at Half Load (min): 15
Runtime at Full Load (min): 5
Typical Recharge Time (Hours): 5
Maximum Charging Current (A): 1
Start On Battery: Yes
Smart Battery Management (SBM): Yes
User-replaceable: No
Battery Type: Sealed Lead-acid
Single Battery Capacity (AH): 12V 7AH
Extended Battery Module (EBM): BPSE72V45A
Max. EBM Quantity (pcs): 3
Extended Battery Module (EBM): BPSE72V45A
Max. EBM Quantity (pcs): 3
SURGE PROTECTION & FILTERING
Surge Suppression (Joules): 440
EMI/RFI Filtration: Yes
Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out
MANAGEMENT & COMMUNICATIONS
LCD Panel: Yes
LCD Information Display: Operation Type , Power Status , Battery Status , Load Status , Fault & Warning , Other Information, Event & Log
LCD Setting & Control: Mode Setting , Alarm Setting , Input & Output , Battery Setting
HID Compliant USB Port(s): 1
Serial Port: RS232
Emergency Power Off (EPO) Port: Yes
Audible Alarms: Battery Mode , Low Battery , Overload ,Overcharge, Overheat, UPS Fault, Replace Battery
Power Management Software: PowerPanel® Business Edition
SNMP/HTTP Remote Monitoring: Yes – with optional RMCARD205
PHYSICAL
Form Factor: Tower
Enclosure Construction: Metal
Color: Black
PHYSICAL SIZE – UPS MODULE
Dimensions (WxHxD) (mm.): 196 x 337 x 416
Weight (kg.): 23.8
ENVIRONMENTAL
Operating Temperature (°C): 0 ~ 40
Operating Relative Humidity (Non-condensing) (%): 20 ~ 90
Operating Elevation (feet/meters): 0-5,000 feet (0-1,500 meters)
Storage Temperature (°C): -20 ~ 50
Storage Relative Humidity (Non-condensing) (%): 10 ~ 90
Online Thermal Dissipation (BTU/hr): 665
CERTIFICATIONS
Certifications: CE,EAC, LOA
RoHS: Yes
